Specificaties
Aansluitingsgrootte
1-1/4 Zoll
Aansluitingstype
Rotalock
Aantal cilinders
4
Diameter
352 mm
Diameter vloeistofleiding
352 mm
Elektrische aansluiting
Screw connectors 10-32 UNF x 9,5
Hoogte
519 mm
IP-certificering
IP54 (with cable gland)
Inlaat
1 1/8 Zoll
Koelvermogen
6,8 kW
Net Frequentie
50 / 60 Hz
Olievulling
3,9 l
Slagvolume
215,00 cm³
Toelaatbare bedrifsoverdruk drukzijde
28,5 bar
Toelaatbare bedrifsoverdruk zuigzijde
22,6 bar
Type
NTZ215A4LR1B
Uitlaat
3/4 Zoll
Voedingsspanning
400 V
gewicht zonder verpakking
63,67 kg
Daten und Abbildungen ohne Gewähr
